| The general purpose optic leak detection switch is an excellent choice for leak detection in and around secondary containment sumps, tanks and pipes. The submersible sensor may be universally mounted in the interstitial space of the tank. The internal 1A relay provides a reliable switch interface with indicators, PLCs, SCADAs and alarms. |
|
|
|
Fail-safe leak sensor inverts wet to alert user for maintenance |
|
Rugged PP or PFA Teflon® probe and cable rated NEMA 6 |
|
1A relay selectable NO or NC via power supply wiring polarity |
|
Compatible with MicroPoint multi-channel indicator |
|
| Tech Tip |
| Both the submersible sensor probe and cable jacket are constructed of the same rugged PP or PFA Teflon® material per your order. This unique packaging design is completely sealed for maximum reliability and ease of installation within your secondary containment vessel. |
|
|
Specifications
|
|
Orientation:
|
Universal
|
|
Repeatibility:
|
± 0.5 mm in water
|
|
Supply voltage:
|
12-36 VDC
|
|
Contact type:
|
(1) SPST relay (NO/NC)
|
|
Contact rating:
|
60 VA
|
|
Process temp:
|
F: -40° to 194°
C: -40° to 90°
|
|
Pressure:
|
150 psi (10 bar)
|
|
Cable length:
|
10' (3m)
|
|
Sensor rating:
|
NEMA 6 (IP68)
|
|
Process mount:
|
3/4" NPT (3/4” G)
|
|
Sensor material:
|
PP / PFA Teflon®
|
|
Classification:
|
General purpose
|
|
 |
|
|
|
|
