Unitronics is a global company, a designer, developer, producer & marketer of Programmable logic Controllers (PLCs) the computer ‘brains’ that automate mass production lines. Our mission is to make automation simple, efficient, & cost-effective. Our vision is to leverage automation technology with cutting-edge communication technology.

Unitronics Products

Unitronics Automation Products:
PLC & Color Touchscreen HMI
Vision350™Vision350




Power PLC, 3.5" Color Touchscreen, onboard, expandable I/Os (up to 512)
More information


Vision570™
Vision570
Power PLC, 5.7" Color Touchpanel, Snap-in & expansion I/Os (up to 512)
More information


PLC & Touchpanel HMI

Vision280™
Vision280
Advanced PLC, 4.7" Touchanel and keyboard, Snap-in and expansion I/Os (up to 256)
More information


Vision290™
Vision290
Advanced PLC 5.7" Touchanel, Snap-in and expansion I/Os (up to 256)
More information


Vision530™
Vision530
Advanced PLC 5.7" Touchanel, Snap-in and expansion I/Os (up to 256)
More information

PLC & Graphic HMI
Vision120™
Vision120
Small-and-powerful PLC, 2.4" Graphic LCD display and keypad, onboard, expandable I/Os (up to 166)
More information


Vision130™
Vision130
Small-and-powerful PLC, 2.4" Graphic LCD display and keypad, onboard, expandable I/Os (up to 256)
More information


Vision230™
Vision230
Advanced PLC, 3.2" Graphic LCD display and keyboard, Snap-in and expansion I/Os (up to 256)
More information


Vision260™
Vision260
Advanced PLC, 5.4" Graphic LCD display and keyboard, Snap-in and expansion I/Os (up to 256)
More information


PLC & Text HMI

Jazz™
Jazz
Much more than a "smart relay". Full function PLC & HMI, with up to 40 onboard I/Os
More information


M90/M91™
M90/91
Palm-size PLC, 2-line LCD display and keypad, up to 38 onboard I/Os (expandable up to 134)
More information


Unitronics Part Numbers and Description


JZ10-11-R10 24VDC, 6 Digital inputs, 4 Relay outputs

JZ10-11-R16 24VDC, 6 Digital inputs, 2 Digital/Analog inputs (0-10V), 2 Analog inputs (0-20mA), 6 Relay outputs

JZ10-11-R31 24VDC, 16 digital inputs, 2 digital/analog inputs, 2 analog inputs, 11 relay outputs

JZ10-11-T10 24VDC, 6 Digital inputs, 4 Transistor outputs

JZ10-11-T17 24VDC, 6 Digital inputs, 2 Digital/Analog inputs, (0-10V), 2 Analog inputs (0-20mA), 7 Transistor
outputs

JZ10-11-T40 24VDC, 16 digital inputs, 2 digital/ analog inputs, 2 analog inputs, 20 transistor outputs

JZ10-11-PT15 24VDC, 3 digital inputs, 3 digital/analog inputs, 3 PT1000/NI1000, 5 relay outputs, 1 transistor output

JZ-PRG Programming kit. Includes software CD, Programming add-on port, programming cable, D-type adapter

JZ-RS4 RS232/RS485 add on port, cable and adapter

MJ20-MEM1 Program cloner

MJ20-JZ-SL1 Extra keypad slide set (blank)

M90-19-B1A 24VDC, 10 Digial Inputs, 6 Relay Outputs, 1 Analog Input, RS232

M90-T 24VDC, 8 Digial Inputs, 6 Transistor Outputs, RS232

M90-TA2-CAN 24VDC, 10 Digial Inputs, 8 Transistor Outputs, 2 Analog Inputs, 1 Analog Output, RS232, CANbus

M91-2-R1 12/24VDC, 10 Digial Inputs, 6 Relay Outputs, 1 Analog Inputs, RS232/485

M91-2-R2C 12/24VDC, 10 Digial Inputs, 6 Relay Outputs, 2 Analog Inputs, RS232/485, CANbus

M91-2-R6C 24VDC, 6 Digial Inputs, 6 Relay Outputs, 6 Analog Inputs, RS232/485, CANbus

M91-2-R34 24VDC, 20 Digial Inputs, 2 Analog/Digital Inputs, 12 Relay Outputs, RS232/485

M91-2-T1 12/24VDC, 12 Digial Inputs, 12 Transistor Outputs, RS232/485

M91-2-T38 24VDC, 22 Digial Inputs, 16 Transistor Outputs, RS232/485

M91-2-T2C 12/24VDC, 10 Digial Inputs, 12 Transistor Outputs, 2 Digital/Analog Inputs, RS232/485

M91-2-UN2 12/24VDC, 10 Digial Inputs, 12 Transistor Outputs, 2 PT100/TC/Analog/Digital Inputs, RS232/485

M91-2-UA2 24VDC, 10 Digial Inputs, 10 Transistor Outputs, 2 TC/Analog/Digital Inputs, 2 Analog Outputs, RS232/485

M91-2-RA22 24VDC, 12 Digital Inputs including 2 Analog inputs and 2 temperature measurement inputs, high speed counter/ shaft encoder input, 8 relay outputs, 2 Analog outputs, RS232/ RS485.

V120-22-R1 12/24VDC, 10 Digial Inputs, 6 Relay Outputs, 1 Analog Inputs, RS232/485 x 2

V120-22-R2C 12/24VDC, 10 Digial Inputs, 6 Relay Outputs, 2 Analog Inputs, RS232/485, CANbus x 2

V120-22-R6C 24VDC, 6 Digial Inputs, 6 Relay Outputs, 6 Analog Inputs, RS232/485, CANbus x 2

V120-22-R34 24VDC, 20 Digial Inputs, 2 Analog/Digital Inputs, 12 Relay Outputs, RS232/485 x 2

V120-22-T1 12/24VDC, 12 Digial Inputs, 12 Transistor Outputs, RS232/485 x 2

V120-22-T38 24VDC, 22 Digial Inputs, 16 Transistor Outputs, RS232/485 x 2

V120-22-T2C 12/24VDC, 10 Digial Inputs, 12 Transistor Outputs, 2 Digital/Analog Inputs, RS232/485 x 2

V120-22-UN2 12/24VDC, 10 Digial Inputs, 12 Transistor Outputs, 2 PT100/TC/Analog/Digital Inputs, RS232/485 x 2

V120-22-UA2 24VDC, 10 Digial Inputs, 10 Transistor Outputs, 2 TC/Analog/Digital Inputs, 2 Analog Outputs,
RS232/485 x 2

V120-22-RA22 24VDC, 12 Digital Inputs including 2 Analog inputs and 2 temperature measurement inputs, high speed counter/ shaft encoder input, 8 relay outputs, 2 Analog outputs, RS232/ RS485.

V130-33-R2 24VDC, 10 Digital Inputs, 2 Analog/Digital Inputs, 6 Relay Outputs, RS232/485

V130-33-R6 24VDC, 6 Digital Inputs, 2 Digital/Analog (current/voltage) Inputs, 4 Analog (current), 6 Relay Outputs, RS232/485

V130-33-R34 24VDC, 20 Digital Inputs, 2 Analog/Digital Inputs, 12 Relay Outputs, RS232/485

V130-33-RA22 24VDC, 8 Digital Inputs, 2 Analog/Digital Inputs, 2 TC/PT/Digital Inputs, 8 Relay Outputs, 2 Analog Outputs, RS232/485

V130-33-T2 24VDC, 10 Digital Inputs, 2 Analog/Digital Inputs, 12 Transistor Outputs, RS232/485

V130-33-T38 24VDC, 20 Digital Inputs, 2 Analog/Digital Inputs, 16 Transistor Outputs, RS232/485

V130-33-TA24 24VDC, 8 Digital Inputs, 2 Analog/Digital Inputs, 2 TC/PT/Digital Inputs, 10 Transistor Outputs, 2
Analog Outputs, RS232/485

V130-33-B1 24VDC, no on-board I/Os, can be connected to expansion modules, RS232/RS485

V350-35-R2 24VDC, 10 Digital Inputs, 2 Analog/Digital Inputs, 6 Relay Outputs, RS232/RS485

V350-35-R6 24VDC, 6 Digital Inputs, 2 Digital/Analog (current/voltage) Inputs, 4 Analog (current), 6 Relay Outputs, RS232/485

V350-35-R34 24VDC, 20 Digital Inputs, 2 Analog/Digital Inputs, 12 Relay Outputs, RS232/RS485

V350-35-RA22 24VDC, 8 Digital Inputs, 2 Analog/Digital Inputs, 2 TC/PT/Digital Inputs, 8 Relay Outputs, 2 Analog Outputs, RS232/RS485

V350-35-T2 24VDC, 10 Digital Inputs, 2 Analog/Digital Inputs, 12 Transistor Outputs, RS232/RS485

V350-35-T38 24VDC, 20 Digital Inputs, 2 Analog/Digital Inputs, 16 Transistor Outputs, RS232/RS485

V350-35-TA24 24VDC, 8 Digital Inputs, 2 Analog/Digital Inputs, 2 TC/PT/Digital Inputs, 10 Transistor Outputs, 2 Analog Outputs, RS232/RS485

V350-35-B1 24VDC, no on-board I/Os, can be connected to expansion modules, RS232/RS485

V100-17-RS4 1 RS232/RS485 port

V100-17-RS4X
1 RS232/RS485 port (Isolated)

V100-17-ET2 1 Ethernet port

V100-17-CAN 1 CANbus port (Isolated)

V130-33-SL1 Extra keypad slide set (blank) for V130 (in V350 an extra slide is included in the product package)

V230-13-B20B GRAPHIC 128X64, CAN, 2 RS232

V260-16-B20B GRAPHIC 240X64, CAN, 2 RS232

V280-18-B20B 4.7"
Touchscreen (320X240) + keyboard, CAN, 2 RS232

V290-19-B20B 5.7" Touchscreen (320X240), CAN, 2 RS233

V530-53-B20B 5.7" Touchscreen (320X240), CAN, 1 RS234, 1 RS232/485

V290-19-T40B 5.7" Color Touchscreen, TFT (320X240), CAN, 2 RS232/485

V570-57-C30B 5.7" Color Touchscreen, CSTN (320X240), CAN, 2 RS232/485

V570-57-T40B 5.7"
Color Touchscreen, TFT (320X240), CAN, 2 RS232/485

V200-18-E1B
16 Digital Inputs, 10 Relay Outputs, 4 Transistor Outputs, 3 Analog Inputs, 24VDC

V200-18-E2B
16 Digital Inputs, 10 Relay Outputs, 4 Transistor Outputs, 2 Analog Inputs, 2 Analog Outputs, 24VDC

V200-18-E3XB 18 Digital Inputs, 15 Relay Outputs, 2 Transistor Outputs, 4 Analog Inputs, 4 Analog Outputs, 24VDC

V200-18-E4XB 18 Isolated Digital Inputs, 2 Isolated pnp/npn Transistor Outputs, 15 Isolated pnp Transistor Outputs, 4 Isolated Analog (14 bit)/Thermocouple/PT100 Inputs (Res. 0.1˚), 4 Isolated Analog Outputs (12 bit), 24VDC

V200-18-E5B 18 Isolated Digital Inputs, 2 Isolated pnp/npn Transistor Outputs, 15 Isolated pnp Transistor Outputs,
3 Analog (10 bit) Inputs, 24VDC

V200-18-E6B 18 Digital Inputs, 15 Relay Outputs, 2 Transistor Outputs, 3 Analog Inputs, 2 Analog/ Thermocouple/ PT100 Inputs, 2 Analog Outputs

V200-19-R4 1 RS485 port

V200-19-ET1 1 Ethernet port

V200-19-RS4-X 1 RS232/RS485 (Isolated)

EX-A1 Local expansion adapter, 12/24VDC

EX-RC1 Remote expansion adapter via CANbus, 12/24VDC

IO-DI8-TO8 8 Digital Inputs / 8 Transistor Outputs, 24VDC

IO-DI8-RO4
8 Digital Inputs / 4 Relay Outputs, 24VDC

IO-DI8-RO8 8 Digital Inputs / 8 Relay Outputs, 24VDC

IO-DI16 16 Digital Inputs, 24VDC

IO-RO8
8 Relay Outputs, 24VDC

IO-RO16 16 Relay Outputs, 24VDC

EX90-DI8-RO8 8 Digital Inputs / 8 Relay Outputs, 24VDC

IO-DI8-TO8-L 8 Digital Inputs / 8 Transistor Outputs, 12VDC

IO-DI8-RO4-L 8 Digital Inputs / 4 Relay Outputs,12VDC

IO-DI8-RO8-L 8 Digital Inputs / 8 Relay Outputs,12VDC

IO-DI16-L 16 Digital Inputs, 12VDC

IO-RO8L 8 Relay Outputs, 12VDC

IO-RO16-L 16 Relay Outputs, 12VDC

IO-TO16
16 Transistor Outputs, 12/24VDC

IO-DI8ACH 8 110/220VAC Digital Inputs

IO-AI4-AO2 4 Analog Inputs / 2 Analog Outputs

IO-AO6X 6 Isolated Analog Outputs

IO-PT400 4 PT100 / NI100 / NI120 Inputs

IO-PT4K 4 PT1000 / NI1000 Inputs

IO-ATC8 8 Thermocouple/Analog Inputs

IO-LC1 1 Loadcell/Strain gauge Input, 1 Digital Input / 1 Setpoint Digital Output

IO-LC3 3 Loadcell/Strain gauge Inputs, 1 Digital Input / 1 Setpoint Digital Output

GSM-KIT-14J GPRS/GSM Kit, Siemens TC65T Modem, Quad band

GSM-KIT-41J GPRS/GSM Kit, Enfora GSM1208, Quad Band

PS-24-11A Power Supply, 24V,1.1A, for PLCs and modem

M90-19-R4 RS232 to RS422/485 converter

MJ10-22-CS35 USB to RS232 converter

MJ10-22-CS65 RS485 plug for V120

MJ10-22-CS66
RS485 plug for V230/260/280

EX1-CA050 Expansion cable (0.5m)

EX1-CA100 Expansion cable (1m)

EX1-CA200 Expansion cable (2m)

EX1-CA400 Expansion cable (4m)

EX1-CA500 Expansion cable (5m)

EX1-CA600 Expansion cable (6m)


Click to download an Excel File of Unitronics part numbers and descriptions
