| Installed through the side wall, this general purpose high or low level switch package includes a 10A compact relay controller for pump or valve actuation with an optional flash alarm. The product is typically selected for bulk storage, day tank and process vessel applications. Specify the appropriate sensor technology and material. |
|
|
|
|
|
Fail-safe relay control of pumps and valves with 0-60 second time delay |
|
PP, Ryton® or PFA wetted material for challenging corrosive liquids |
|
Optional strobe brings immediate attention to tank alarm conditions |
|
Offered in 2 sensing technologies for broad application coverage |
|
| Tech Tip |
Sensor Technology |
The AC powered relay controller has a 10A relay, adjustable time delay, LED indicators, NO or NC invert switch and UL fire retardant PP enclosure. The optional Strobe Alert flashes during a high or low level alarm condition.
|
Ultrasonic
Broadly applied in chemical, solvent, hydrocarbon and light weight oil media
Vibration
Typically applied in wastewater media with light coating and/or foaming characteristics
|
|
|
|
Specifications
|
|
Orientation:
|
± 20° horizontal
|
|
Supply voltage:
|
120/240 VAC @ 50-60 Hz.
|
|
Contact type:
|
(1) SPST relay
|
|
Contact rating:
|
250 VAC @ 10A
|
|
Process temp:
|
F: -40° to 176°
C: -40° to 80°
|
|
Pressure:
|
150 psi (10 bar)
|
|
Wetted material:
|
AU13: PP/PFA
AZ13: Ryton®
|
|
Conduit entrance:
|
1/2" NPT
|
|
Enclosure rating:
|
NEMA 4X (IP65)
|
|
Process mount:
|
3/4" NPT (3/4" G)
|
|
Classification:
|
General purpose
|
|
|
|
